Product Features:

- Condenser fans: propeller type of heavy-duty construction, dynamically balanced and suitable for operation up to 80°C ambient, Fans are driven by TEAO motors with Class B/F insulation, The fan blade pitch Angle is designed for maximum airflow and minimum noise.

- High efficiency compressors: Compressor’s type of an advanced design ensuring high Energy, Efficiency Ratio, less noise, less vibration, and outstanding endurance.

-  Fresh air intake panel: A fixed outdoor air intake connection that is designed for 25% fresh air is available as standard, Fresh air dampers are optional for field / factory installation.

-  Complete factory package-tested, charged and wired: Every unit is completely piped, wired, charged and tested at the factory to simplify the field installation and to provide years of dependable operation.

-  Single point power connection for easy installation.

Technical Specifications:

       - Nominal Cooling Capacity (Tons): 5

       - Voltage (V/PH/HZ): 230/1/60

       - Dimensions (HxWxL): 1208X1189X1749 mm

       - Unit Weight (KG): 633

      * Please refer to the catalogue for all technical aspects

      ** Terms and conditions apply
